Amplifiers
Text Box:

RF Microwave Amplifier

S2D Microwave Amplifiers cover a wide frequency range from 10MHz to 65 GHz. Amplifiers can be built to design or print specification and are available in different package specification as per requirements.

General Specifications

¨ Covers broad frequency range from 10 MHz to 65 GHz

¨ Noise figure as low as 1dB

¨ Excellent VSWR

¨ Operating Temperature –40°C to 85°C

¨ Operating Voltage: +5/+12/+15/+18V

¨ Reverse voltage protection

¨ Internal regulator for steady performance

¨ Gain and P1 dB can be optimized to support your specification

¨ Hermetic sealing option available

¨ Field replaceable connectors

¨ Available in compact packages

¨ Surface mount or connector packages

Low Noise Amplifier

Broadband Low Noise Amplifiers offer gain up to 60 dB and P1 dB to 20 dBm



Medium Power Amplifier

Broadband Medium Power Amplifiers offer gain up to 60 dB and P1 dB to 33 dBm



High Power Amplifier

Broadband Low Power Amplifiers offer gain up to 60 dB, P1 dB to 100 dBm CW, and Peak Power to 1KW



S3

LOW NOISE AMPLIFIER

MEDIUM POWER AMPLIFIER

HIGH POWER AMPLIFIER

S3

S3

S4A

S1

Text Box: 	       Microwave

S2D

Model

Frequency Range GHz

Noise Figure dB Max.

Gain dB Min.

OIP3

P1dB dBm Min.

Current 12-15 V mA

VSWR

Package Style

S3-A142212033

0.3-3.0

1.7

14

32

22

240

2.2:1



S5AT

S3-A31211206104

0.6-1.6

1.1

31

31

21.5

400

2.0:1

S3-A19211224

2.0-4.0

3.2

19

31

21

320

2.0:1

S3-A141612037

3.5-7.0

2.6

14

26

16

190

2.0:1

S3-A111612520

5.0-20.0

2.4

11

25

16

150

2.4:1

S3-A171512618

6.0-18.0

1.8

15

26

17

210

2.0:1

S3-A201012620

6.0-20.0

2.5

20

20

10

170

2.0:1

S3-A171612510

5.0-10

2.0

17

26

16

210

2.0:1

S3-A1216120120

0.1-20.0

3.0

12

24

16

100

2.2:1

S3-A131512220

2.0-20.0

2.9

13

23

15

100

2.2:1

S3-A2010512

1.0-2.0

2.0

20

22

10

270

2.0:1

S3-A22105813

8.0-13.0

1.9

22

20

10

120

2.0:1

S3-A35195818

8.0-18.0

2.5

35

27

19

270

2.0:1

S1-A202050054

0.05-4.0

1.6

20

28

20

100

2.0:1

S5AT-A312012118

1.0-18.0

3.0

31

30

20

400

2.0:1



















































Model

Frequency Range GHz

Noise Figure dB Max.

Gain dB Min.

OIP3

P1dB dBm Min.

Current 12-15 V mA

VSWR

Package Style

S3-A12271205205

0.5-2.5

6.2

12

42

27

300

2.0:1

S51

S3-A18251207208

0.7-2.8

4.0

18

42

25

250

2.0:1

S3-A202012520

5.0-20.0

6.7

20

30

20

250

2.0:1

S3-A162012618

6.0-18.0

4.7

16

32

20

220

2.0:1

S3-A2827121011

9.5-11.5

6.2

28

33

27

480

2.0:1

S3-A2022120054

0.05-4.0

1.7

20

30

22

150

2.0:1

S51-26291512

1.0-2.0

5.0

25

37

27

800

2.0:1

S51-253015R66

0.6-6.0

6.0

25

38

28

1000

2.0:1



















































Model

Frequency Range GHz

Noise Figure dB Max.

Gain dB Min.

OIP3

P1dB dBm Min.

Current 12-18V mA

VSWR

Package Style

S4A-14331204207

0.4-2.7

8.7

14

48

33

900

2.2:1

S51

S4A-20271234

3.0-4.0

5.2

20

40

27

350

2.1:1

S4A-173312610

6.0-10.0

-

17

43

33

1700

2.0:1

S4A-2834121215

12.0-15.0

-

28

42

34

1500

2.0:1

S4A-1138480210

0.2-10.0

-

11

47

38

48V/1500

2.0:1

S4A-2636121215

12.0-15.0

-

26

44

36

1500

2.0:1

S4A-2632121215

12.0-15.0

-

26

40

32

1500

2.0:1

S3-A30280515218

2.0-18.0

-

30

36

28.5

1800

2.2:1

S51- 243318063

0.6-2.7.0

-

24

40

31

1800

2.2:1

S51- 253318066

0.6-6.0

-

25

40

31

1800

2.2:1

S51-353318112

1.0-12.0

-

35

42

31

2000

2.2:1

S51- 343315618

6.0-18.0

-

34

44

32

1800

2.2:1
