Passive Limiter |
|
General Specifications ¨ Wide frequency range from 100 MHz to 65 GHz ¨ Power handling from 1W CW to 50W CW ¨ Low Insertion Loss ¨ Low Leakage ¨ Excellent VSWR ¨ Fast recovery time ¨ Internal DC Return ¨ Available in compact rugged packages ¨ Hermetic sealing option available |
|
S2D Microwave, Inc. reserves all the rights to change any specification without notice.. |
|
Environmental Rating ¨ Operating Temperature: -40°C to +85°C ¨ Storage Temperature: -65°C to +125°C ¨ Shock: MIL-STD-202F, Method 213B Cond B (75G, 6msec) ¨ Vibration: MIL-STD-202F, Method 204D Cond B (15G) ¨ Humidity: MIL-STD-202F, Method 103B Cond B (96 hours at 95% R.H.) ¨ Altitude: MIL-STD-202F, Method 105C Cond B (50,000 feet) ¨ Temperature Cycle: MIL-STD-202F, Method 107D Cond A (5 cycles) |
|
S2D |
|
PASSIVE LIMITER PERFORMANCE MATRIX |
||||||
|
Test Conditions: VSWR and Insertion loss tested@ 0 dBm Power in @ 25°C Note: we design and develop per customer requirement. Please contact factory. |
||||||
|
MODEL |
FREQUENCY RANGE GHz |
MAX INSERTION LOSS dB |
MAX VSWR dB |
TYP LIM THRESHOLD dBm |
MAX LEAKAGE @ 1W CW INPUT dBm |
PACKAGE STYLE |
|
LR1052 |
0.5 - 2.0 |
0.5 |
1.4 |
+9 |
+20 |
|
|
LR1054 |
0.5 - 4.0 |
0.7 |
1.4 |
+9 |
+20 |
|
|
LR1056 |
0.5 - 6.0 |
1.2 |
1.4 |
+9 |
+20 |
|
|
LR10512 |
0.5 - 12 |
1.6 |
1.6 |
+9 |
+20 |
|
|
LR10516 |
0.5 - 16 |
1.7 |
1.6 |
+9 |
+20 |
|
|
LR10518 |
0.5 - 18 |
1.8 |
2 |
+9 |
+20 |
|
|
LR112 |
1.0 - 2.0 |
0.6 |
1.4 |
+9 |
+19 |
|
|
LR114 |
1.0 - 4.0 |
0.7 |
1.5 |
+9 |
+19 |
|
|
LR116 |
1.0 - 6.0 |
1.2 |
1.5 |
+9 |
+19 |
|
|
LR1112 |
1.0 - 12 |
1.6 |
1.6 |
+9 |
+19 |
|
|
LR1114 |
1.0 - 14 |
1.7 |
1.6 |
+9 |
+19 |
|
|
LR1116 |
1.0 - 16 |
1.8 |
1.7 |
+9 |
+19 |
|
|
LR1118 |
1.0 - 18 |
1.8 |
2 |
+9 |
+20 |
|
|
LR124 |
2.0 - 4.0 |
0.7 |
1.4 |
+9 |
+19 |
|
|
LR128 |
2.0 - 8.0 |
1.3 |
1.5 |
+9 |
+19 |
|
|
LR1212 |
2.0 - 12 |
1.4 |
1.6 |
+9 |
+19 |
|
|
LR1218 |
2.0 - 18 |
1.8 |
2 |
+9 |
+20 |
|
|
LR1612 |
6.0 - 12 |
1.7 |
1.8 |
+9 |
+19 |
|
|
LR1618 |
6.0 - 18 |
1.8 |
2 |
+9 |
+19 |
|
|
LR1713 |
7.0 - 13 |
1.7 |
1.6 |
+9 |
+19 |
|
|
LR1816 |
8.0 - 16 |
1.7 |
1.7 |
+9 |
+19 |
|
|
LR1818 |
8.0 - 18 |
1.8 |
2 |
+9 |
+19 |
|
|
LR11018 |
10 - 18 |
1.8 |
2 |
+9 |
+19 |
|
|
LR1620 |
6 - 20 |
2.4 |
2 |
+9 |
+19 |
|
|
LR11020 |
10 - 20 |
2.4 |
2 |
+9 |
+19 |
|
