Reflective Switches |
|
¨ SPST -to- SP64T ¨ KHz—65GHz ¨ Low Insertion Loss ¨ High Isolation to 85 dB ¨ Excellent VSWR ¨ Integral TTL Drivers ¨ Field replaceable connectors |
|
S2D Microwave, Inc. reserves all the rights to change any specification without notice. Above specifications are based on calculations
|
|
¨ 30 ns typical switching speed : 10%TTL to 90%RF ¨ Operating Voltage: +/-5 V, +5/-12 V ¨ Operating Temperature Range: -54°C—+84°C ¨ Amplitude and Phase matched models available ¨ Reverse voltage protection ¨ Surface mount or connector packages ¨ Hermetic sealing option available |
|
General Specifications |
|
Reflective Switch Performance Matrix |
|
S2D |
|
TYPE |
MODEL |
FREQUENCY GHz |
INSERTION LOSS Max dB |
ISOLATION Min dB |
VSWR Max |
Datasheet / Outline |
|
SPST |
|
|
|
|
|
|
|
|
S2-01R55R52 |
0.5 - 2.0 |
1.0 |
65 |
1.5:1 |
|
|
|
S2-01R5524 |
2.0 - 4.0 |
1.0 |
65 |
1.6:1 |
|
|
|
S2-01R5548 |
4.0 - 8.0 |
1.3 |
65 |
1.6:1 |
|
|
|
S2-01R55812 |
8.0 - 12.0 |
1.6 |
65 |
1.7:1 |
|
|
|
S2-01R551220 |
12.0 - 20.0 |
2.2 |
65 |
2.0:1 |
|
|
|
S2-01R55R520 |
0.5 - 20.0 |
2.2 |
65 |
2.0:1 |
|
|
SP2T |
|
|
|
|
|
|
|
|
S2-02R512R52 |
0.5 - 2.0 |
1.1 |
70 |
1.5:1 |
|
|
|
S2-02R51224 |
2.0 - 4.0 |
1.1 |
65 |
1.6:1 |
|
|
|
S2-02R51248 |
4.0 - 8.0 |
1.3 |
65 |
1.7:1 |
|
|
|
S2-02R512812 |
8.0 - 12.0 |
1.8 |
60 |
1.7:1 |
|
|
|
S2-02R5121220 |
12.0 - 20.0 |
2.6 |
60 |
2.0:1 |
|
|
|
S2-02R512R520 |
0.5 - 20.0 |
2.6 |
60 |
2.0:1 |
|
|
SP3T |
|
|
|
|
|
|
|
|
S4-03R55R52 |
0.5 - 2.0 |
1.1 |
70 |
1.5:1 |
|
|
|
S4-03R5524 |
2.0 - 4.0 |
1.1 |
65 |
1.6:1 |
|
|
|
S4-03R5548 |
4.0 - 8.0 |
1.3 |
65 |
1.7:1 |
|
|
|
S4-03R55812 |
8.0 - 12.0 |
1.8 |
60 |
1.8:1 |
|
|
|
S4-03R551220 |
12.0 - 20.0 |
2.6 |
60 |
2.0:1 |
|
|
|
S4-03R55R520 |
0.5 - 20.0 |
2.6 |
60 |
2.0:1 |
|
|
SP4T |
|
|
|
|
|
|
|
|
S4-04R55R52 |
0.5 - 2.0 |
1.2 |
70 |
1.5:1 |
|
|
|
S4-04R5524 |
2.0 - 4.0 |
1.2 |
65 |
1.6:1 |
|
|
|
S4-04R5548 |
4.0 - 8.0 |
1.4 |
65 |
1.7:1 |
|
|
|
S4-04R55812 |
8.0 - 12.0 |
2.0 |
60 |
1.8:1 |
|
|
|
S4-04R551220 |
12.0 - 20.0 |
2.7 |
60 |
2.0:1 |
|
|
|
S4-04R55R520 |
0.5 - 20.0 |
2.7 |
60 |
2.0:1 |
|
|
SP5T |
|
|
|
|
|
|
|
|
S4-05R55R52 |
0.5 - 2.0 |
1.2 |
70 |
1.5:1 |
|
|
|
S4-05R5524 |
2.0 - 4.0 |
1.2 |
65 |
1.6:1 |
|
|
|
S4-05R5548 |
4.0 - 8.0 |
1.4 |
65 |
1.7:1 |
|
|
|
S4-05R55812 |
8.0 - 12.0 |
2.0 |
60 |
2.0:1 |
|
|
|
S4-05R551220 |
12.0 - 20.0 |
3.0 |
60 |
2.0:1 |
|
|
|
S4-05R55R520 |
0.5 - 20.0 |
3.0 |
60 |
2.0:1 |
|
|
SP6T |
|
|
|
|
|
|
|
|
S6-06R55R52 |
0.5 - 2.0 |
1.3 |
70 |
1.8:1 |
|
|
|
S6-06R55218 |
2.0 - 18.0 |
3.2 |
60 |
2.0:1 |
|
|
SP7T |
|
|
|
|
|
|
|
|
S5-07R512R52 |
0.5 - 2.0 |
1.3 |
70 |
1.8:1 |
|
|
|
S5-07R512218 |
2.0 - 18.0 |
3.6 |
60 |
2.0:1 |
|
|
SP8T |
|
|
|
|
|
|
|
|
S6-08R55R52 |
0.5 - 2.0 |
1.3 |
70 |
1.8:1 |
|
|
|
S6-08R55218 |
2.0 - 18.0 |
3.8 |
60 |
2.0:1 |
|
|
|
S7-08R55R52 |
0.5 - 2.0 |
1.5 |
70 |
1.8:1 |
|
|
|
S7-08R55218 |
2.0 - 18.0 |
4.2 |
60 |
2.0:1 |
|
|
SP10T |
|
|
|
|
|
|
|
|
S61-10R55R52 |
0.5 - 2.0 |
1.5 |
70 |
1.8:1 |
|
|
|
S61-10R55218 |
2.0 - 18.0 |
4.2 |
60 |
2.0:1 |
|
|
SP22T |
|
|
|
|
|
|
|
|
S11-22R55R52 |
0.5 - 2.0 |
2.2 |
70 |
1.8:1 |
|
|
|
S11-22R55218 |
2.0 - 18.0 |
6.0 |
60 |
2.0:1 |
|
