RF Microwave Attenuator

S2D Microwave RF Attenuators cover a wide frequency range from 5 MHz to 20 GHz with a constant attenuation within the range of 0.25dB to 100dB as per customer requirement with minimal reflection. They are available in either of two types: voltage/current controlled or digital control.

Fixed Attenuator

Fixed Attenuators has a fixed attenuation value ranging from 2dB to 64dB



Variable Attenuator

Variable Attenuators comes in variable attenuation to 100dB



Step Attenuator

Step Attenuators changes the attenuation in step to 100dB



Programmable Attenuator

Programmable Attenuators can be programmed to attain an attenuation as per customer specification within a range from 0.25db to 100dB



Switched Bit Attenuator

Switched Bit Attenuators are available from single bit to six bit attenuation ranging from 1 dB to 100 dB

General Specifications

 Wide frequency range 5MHz to 20Ghz

 Attenuator range from 0.25dB to 100dB

 Excellent VSWR

 Integral TTL Drivers

 RF input power +10 dBm

 Input / Output 50 Ohms impedance match

 Extremely fast switching with stable attenuation

 Operating Voltage: +/-5 V , +5/-12 V, +/-15V

 Standard packages are available

 Hermetic sealing option available

S2D Microwave, Inc. reserves all the rights to change any specification without notice..

Attenuator Models

Switched Bit Attenuator Models

MODEL

Frequency Range GHz

Datasheet / Outline

S0-AT5200010

HZ - 10.0



S3-AT550009

DC - 9.0



S3-AT205579

7.0 - 9.0



S5AT-0264512R518

3.5 - 7.0



S5AT-02305578

7.0 - 8.0



S5AT-026255218

2.0 - 18.0



S5AT-30605578

7.0 - 8.0



S5AT-6155R5207

0.5 - 20.0



MODEL

Bits

Frequency Range GHz

Datasheet / Outline

S3-AS1055R520

1

0.5 - 20

S3-AS3055R520

2

0.5 - 20



S3-AS6055R520

3

0.5 - 20
